The T1750 is a heavy-duty wagon with drive. The trailer is built with a center beam construction 90*90*4 (100*100*3). You can change the length of the trailer by 60 cm, from 168cm to 228 cm between the banks.

The trolley has a Crane man 30-50 crane with comfort joint that makes the stick on the crane have 180 degree movement. The cylinders and hoses for the drive roller in and out are well protected on the bogie arm.

Kranman has developed its own wheel that is adapted for drive roller. The wheel has an extra strong pattern and a tread infused to get maximum grip and minimal friction (Kranman wheels are standard).

Note! The T1750 in tractor version does not include aggregates, where of the price difference from the T1750 for ATV.

Specification

Weight360 kg
Total length382 cm
Width142 cm
Length between banks:226-286 cm
Height over gate 165 cm
My height between bangs168 cm
Wheels26x12.00-12" 8 ply
Loading area0.9 m²
Clearance30 cm
Weight crane276 kg, incl. support legs, gate, grapple and valve package
Max load1 750 kg
